Responsive tactile feedback offering two types, with and without a click-feel. The rich lineup of options broadens the scope for designs
- Button sizes
The provision of four types of button sizes (6 square type, 8
square type, 10 square type and 12 square type), it is possible to
a sense of unity in panel designs.
- Depth behind panel
The overall length of switches is unified at 18mm. A short depth
behind the panel of over 12mm.
- Illumination component
LEDs are used as the light-emitting devices to achieve full-face
and dual color.
The soft illumination produces a high-quality feeling.
- Switch component
The use of a twin contact structure ensure high contact reliability.
Can be used from a minimum load of DC 1.5V, 10μA.
Two types are available, with and without a click-feel.
- Terminal
This is a product designed to prevent flux entry when mounting.
- Accessories
Cosmetic flanges are available for the 10 square type and 12
square type buttons, broadening the scope for designs.
- Design
A soft design with attention to fine details such as the rounded
finish given to corners.
A printed‑circuit mounted switch effective with very little current loaded featuring a soft design and a range of four button sizes.
KC Lighted Pushbutton Switches
